VIBCO Products - JVS/ACE Internal concrete vibrator

internal concrete vibrator jvs ace series vibco vibrators

JVS & ACE Electric Internal Vibrators

Interchangeability is VIBCO's solution to making the tough job easy.

• Heavy Duty Universal Motor
• Interchangeable Heads
• Interchangeable Flexible Shafts
• Reversible Shafts for Double Life
• Shafts Available Up to 21 Ft.


1. MOTOR OPTIONS: You have 2 motors to choose from; Model JVS 1.5 HP or Model ACE 2.5 HP.

2. HEAD SIZE OPTIONS: 3/4" - 1" head diameter use: thinnest prestressed sections of burial vaults, manholes,etc.
1-1 /4" - 1-112" head diameter use: thin prestressed sections manholes, pipes, septic tanks, etc.
1-3/4" head diameter use: the most versatile and general purpose head; ideal for floors, slabs, walls, columns, bridge decks, railings,
2" head diameter use: all around size capable of handling stiff low slump mixes, heavy open forms, large foundations, retaining walls/
2-1 /2" head diameter use: enough force for the stiffest low slump heavy bridge work, etc.

Since the motor is carried at waist height when wearing the shoulder strap, choose the strap length of appropriate waist height plus form depth. Each Motor has 3 different lengths to choose from

A Versatile and Durable Solution

VIBCO's Silent electric vibrators are totally enclosed and can be used inside or outside, in dust, dirt, rain or snow. They solve a wide variety problems - speeding the flow of bulk materials through any size bin, hopper or chute, packing material in drums and bags, consolidating concrete, aiding the efficiency of material through screens - whatever your challenge, VIBCO has an electric vibrator solution.

VIBCO electric vibrators are long lasting and provide years of service under even the toughest conditions. We even offer some models specially designed for corrosive environments. Electric vibrators typically have 2-3 times the life expectancy of air-operated units.

Unmatched Depth and Breadth of Electric Vibrators

With more than 150 electric models to choose from, VIBCO has an electric vibrator to suit your specific needs including adjustable speed and force, heavy duty, high frequency and explosion proof models. VIBCO's Big BerthaTM Dumpbody Vibrators and SandBusterTM Spreader Hopper Vibrators are perfect for trucking and mobile applications
